Geberit Duofix frame for wall-hung WC 79cm with low-height concealed cistern

Geberit Duofix frame for wall-hung WC 79cm with low-height concealed cistern

Application purposes

• For installation in bathroom furniture
• For wall-hung WCs with connection dimensions in accordance with EN 33:2011
• For wall-hung WCs with projection up to 62 cm
• For floor constructions 0–20 cm

Characteristics

• Self-supporting frame, powder-coated
• Frame prepared for support brackets for WC ceramic appliances with small contact surfaces
• Galvanized feet Feet adjustable 0–20 cm
• With large foot plates for raised power supply in floors
• Connection bend can be mounted without tools at different depths, adjustable range 45 mm
• Fastening for connection bend, sound-absorbing
• Flush actuation pneumatic
• Flush pipe connection with compression joint
