Hudson Reed Round Twin Thermostatic Shower Valve / Valve with Diverter
Hudson Reed Round Twin Thermostatic Shower Valve / Valve with Diverter
Couldn't load pickup availability
Slimline design. Can be fitted vertically or horizontally. Accurate flow control. Thermostatic control to +/- 2 degrees even if the water pressure fluctuates. In the event of hot or cold water failure, the valve will shut down the water supply providing full thermal protection and prevents scalding. The unique cartridge is highly resistant to calcium build up - even in hard water areas. Our valves are suitable for use with all systems: gravity fed pumped unvented high pressure or fully modulated combi-boilers. Excellent flow rates - even at low pressure. The cartridge is fully reversible meaning if hot and cold supplies are the wrong way round it doesn't need re-plumbing. Simply remove the cartridge turn 180° and replace. Manufactured from high quality brass & ABS.
Specification
| Product Material | BRASS/ABS |
| Valve/Cartridge Type | 1/4 Turn Ceramic Disc |
| Mount Type |
|
| Head Included | No |
| Handset Included | No |
| Outlet Elbow Included | No |
| Pipe Size | 15 mm (1/2" BSP) |
| Operating Pressure | 0.1 |
| Flow Rate 0.1Bar l/m (Showers) | 5.5 |
| Flow Rate 0.5Bar l/m (Showers) | 14 |
| Flow Rate 1Bar l/m (Showers) | 20 |
| Flow Rate 2Bar l/m (Showers) | 29 |
| Flow Rate 3Bar l/m (Showers) | 44 |
| WRAS Approved (Showers) | Yes |
| WRAS Approval Number (Showers) | 1703023 |
| TMV2 Approved (Showers) | Yes |
| TMV3 Approved (Showers) | Yes |
| TMV2 Approval Number (Showers) | BC 1875 00817 |
| TMV3 Approval Number (Showers) | NSF 1938 1217 |
| Valve Included | Yes |
| Valve Handle Included | Yes |
| Valve Handle Type/Shape | Round Handle |
| No. Of Handles (Showers) | 2 |
| Valve Mount Type | Concealed Shower |
| Shower Valve Style Shape | Round |
| Stain Rust Resistant | Yes |
| Cartridge Included | Yes |
| Commercial Use | No |
| Installation Required | Yes |
| Flow Rate 0.2Bar 1/m (Showers) | 7.1 |
Download the following specifications:
| Product Information | SKU |
|---|---|
| Hudson Reed Round Twin Thermostatic Valve | RND3210 |
| Hudson Reed Round Twin Thermostatic Valve with Diverter | RND3207 |
